Summary

Argo-Hytos R3.1232-56 Replaces the Argo-Hytos R3-1232-56

R3-1232-56
R3-1232-56
Representative product image Product image feedback

Argo-Hytos R3.1232-56 EXAPOR R.GO Element

Brand: Argo-Hytos
Price Match
€238,95
VAT Included
1.5 kg
Germany
8421.99.90
1.72 kg
0.005 m³
France
8421.99.90
2.1 kg
0.005 m³
Italy
8421.99.90
0.005 m³
Germany
8421.39.25
0.005 m³
United Kingdom
8421.99.90
0.005 m³
Germany
8421.99.90
1.87 kg
0.0063 m³
8421.23.00
1.08 kg
0.0057 m³
8421.29.80.90
Shipping Terms

Description

Genuine Argo-Hytos R3.1232-56 EXAPOR R.GO Element.

Specification

StyleEXAPOR R.GO Element

Description

Genuine Argo-Hytos R3.1232-56 EXAPOR R.GO Element.

Argo-Hytos logo

Argo-Hytos Product

Genuine Argo-Hytos R3.1232-56

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β200
Efficiency 2 12µ @ β1000
Style Return Filter
Outer Diameter 114.0 mm
Inner Diameter 68.4 mm
Length 333.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

3.0 BAR
Collapse Pressure 20 BAR
Seal Nitrile
Temperature Range -30 - +100°C
